S 252.01

for S 260 - 266
aluminium
in connection wirh S 260 - 266 usable as hinged extrusion
L 5000 × W 16 × H 16 mm

Available Material

matt anodized, silver (E6/EV1)
Order now.

Technical Data.

Length:

5000 mm

Weight:

1.73 kg

Width:

16 mm

Height:

25 mm

S_252.pdf
S_252.dwg
S_252.dxf

Accessories.

S 257.35

for hinged extrusion S 250

L 35 × W 16 × H 10 mm

light grey

S 260.37

M8

for S 250 / S 252

L 33 × W 16 × H 43 mm

zinc-plated

S 261.37

M8

for S 250 / S 252

L 16 × W 16 × H 43 mm

zinc-plated

S 262.37

for 2 × S 250 / S 252

L 17 × W 17 × H 83 mm

zinc-plated

S 263.37

for 3 × S 250 / S 252

L 31 × W 33 × H 43 mm

zinc-plated

S 264.37

for 4 × S 250 / S 252

L 32 × W 16 × H 83 mm

zinc-plated

S 266.37

for 6 × S 250 / S 252

L 31 × B 33 × H 83 mm

zinc-plated

S 270.37

M8

28-68 mm

L 30 × W 30 × H 70 mm

zinc-plated
