Main  → Tension Fabric Extrusions  → Tension Fabric Extrusions Detail

M 1925.01

for double-sided illumination
aluminium
for double-sided illumination, without system groove, graphics with silicone edge M 1313
L 6000 × W 80 × H 16 mm

Available Material

matt anodized, silver (E6/EV1)
Order now.

Technical Data.

Length:

6000 mm

Weight:

6.546 kg

Width:

80 mm

Height:

16 mm

M_1925.pdf
M_1925.dwg
M_1925.dxf
XM_1925.pdf

Accessories.

M 1313.50

100 meter roll

for fabric

W 14 × H 3 mm

translucent

M 1967.00

straight

for extrusions M 1925 / M 1935

L 180 × W 16 × H 12 mm

raw / unfinished

OL 200.21

for free standing walls

L 600 × W 100 × H 20 mm

silver powder-coated (RAL 9006/IG-54.9006-54)

OL 220.37

opening 20 mm dia.

for ceiling suspension

L 36 × W 36 × H 25 mm

zinc-plated

W 2850.37

M10

L 60 × W 60 × H 75 mm

zinc-plated

W 835.37

for octalumina frames

L 57 × W 30 × H 30 mm

zinc-plated
