Adjustable foot

C 440/F.37

M10

for frame elements

L 40 × W 40 × H 80.5 mm

Frame

W 947/E.01

950 × 2480 mm, door mounting

for fabric and fabric

950 × 2480 mm

Frame

W 945/S.01

mounted above door

W 950 × H 450 × D 40 mm

Frame

W 945/E.01

990 × 450 mm, straight

for fabric and fabric

990 × 450 mm

Frame

W 942/E.01

for double sided fabric

W 950 × H 2480 × D 40 mm

Threaded plate

W 917.00

for C 440/F

L 25 × W 12 × H 21 mm

Base plate

M 1963.21

middle

L 320 × W 250 × H 12 mm

Base plate

M 1961.21

side

L 320 × W 250 × H 301 mm

Base plate

M 1943.21

middle

L 495 × W 170 × H 12 mm

Base plate

M 1941.21

side

L 495 × W 170 × H 301 mm

Fixing set

M 1478.37

for M 1307 / M 1304

for frame connection

L 74 × W 21.7 × H 21.7 mm

Base plate

M 1398.21

for M 1307

L 320 × W 120 × H 8 mm

Base plate

M 1357.21

for M 1307

L 320 × W 300 × H 8 mm

Base plate

M 1347.21

for M 1307

L 320 × W 120 × H 8 mm

Silicone edge

M 1313.50

100 meter roll

for fabric

W 14 × H 3 mm

Frame

W 949/E.01

for double sided fabric

W 455 × H 2480 × D 40 mm
