Cover extrusion | M 1368.01

aluminium

can be powder-coated or film laminated, with slide-on technique for all extrusions 120 mm

L 5000 × W 121 × H 6 mm

Available Material

matt anodized, silver (E6/EV1)

Order now.

Technical Data.

Length:

5000 mm

Weight:

3.1 kg

Width:

121 mm

Height:

6 mm

M_1368.pdf

XM_1368.pdf

M_1368.dwg

M_1368.dxf

Similar Products.

Cover extrusion

W 910.01

for extrusions 40 mm

L 5000 × W 40 × H 5 mm
