Drilling

BS 36.90

8/10 mm drilling

L 140 × W 80 × H 50 mm

Fixing angle

M 1160.37

for extrusions 40/80 mm

L 40 × W 40 × H 60 mm

Reinforcing plate

M 1164.21

with 6 × M 1473

L 240 × W 240 × H 6 mm

Hinged end plate

M 1260.21

for extrusions 80 × 80 mm

L 82 × W 82 × H 109 mm

Adaptor

M 1281.00

for extrusions 80 × 80 mm

L 80 × W 57 × H 19.5 mm

Corner knot

M 1401.01

for cable suspension

L 80 × W 80 × H 124 mm

Spigot tube

M 1424.00

square

L 80 × W 80 × H 404 mm

Wall panel retainer

M 1572.00

top

for extrusions 80 × 80 mm

L 5000 × W 58 × H 6 mm

5000 mm long

Wall panel retainer

M 1577.00

centre

for extrusions 80 × 80 mm

L 5000 × W 58 × H 16 mm

5000 mm long

Internal connector

M 1123.00

straight

L 480 × W 23 × H 57 mm

480 mm long

Adaptor

M 1116.00

with M 1161/L

for extrusions 80 mm

L 46 × W 12 × H 39 mm

Corner connector

M 1115.00

90°

for extrusions 80 × 80 mm

L 160 × W 19.5 × D 160 mm

End cap

M 1034.35

for extrusions 80 × 80 mm

L 80 × W 80 × H 3 mm

End plate

M 1035.21

for extrusions 80 × 80 mm

L 80 × W 80 × H 3 mm

Adjustable foot

M 1038D.37

square

for extrusions 80 × 80 mm

L 82 × W 82 × H 74 mm

Adaptor

M 1101.00

with Z 961/13

for extrusions 80 mm

L 80 × W 19 × H 57 mm

Adaptor

M 1103.00

with 2 × Z 961/13

for extrusions 80 mm

L 80 × W 57 × H 57 mm

Beam retainer

M 1105.00

with set screw M 1105/20

L 75 × W 52 × H 16 mm

Beam retainer

M 1108.37

for adaptor M 1101 / M 1103

L 27 × W 10 × H 10 mm

27 mm long

Adaptor

M 1114.00

with M 1161/R

for extrusions 80 mm

L 46 × W 12 × H 39 mm

Wall panel retainer

M 1581.00

bottom

for extrusions 80 × 80 mm

L 5000 × W 23 × H 44 mm

5000 mm long
